| System Parameter | |||||
| Operating System | Embedded LINUX operating system | ||||
| Network Protocol | IPv4, FTP, RTSP, RTP, TCP, UDP, SIP | ||||
| Keyboard Type | Touch keyboard (0–9, *, #) | ||||
| Basic Parameter | |||||
| Screen Type | Capactive screen | ||||
| Display | 10-inch TFT LCD | ||||
| Resolution | 1024 (H) × 600 (V) | ||||
| Video Compression | H.264 | ||||
| Audio Compression | G.711a, G.711Mu, G.711u, PCM | ||||
| Audio Input | 1 channel all-direction microphone | ||||
| Audio Output | 1 channel | ||||
| Audio Mode | Support dual-way bidirectional talk | ||||
| Audio Enhancement | Support echo suppression/DNR | ||||
| Function Parameter | |||||
| Communication Mode | Full digital | ||||
| Leave Videos or Text Messages | Support | ||||
| DND Mode | Support | ||||
| Sub-station Quantity | 9 | ||||
| Edge Storage | Embedded 8 GB | ||||
| Port | |||||
| Alarm Input | 6 channels | ||||
| Alarm Output | 1 channel | ||||
| Doorbell | Supported by every channel | ||||
| Network | 1 RJ-45, 10 M/100 Mbps self-adaptive | ||||
| Alarm Parameter | |||||
| SOS Alarm | Support | ||||
| General Parameter | |||||
| Casing | PC + ABS | ||||
| Appearance Color | Black | ||||
| Power Supply | Standard PoE DC 12V 1A |
||||
| Power | Optional | ||||
| Installation | Surface | ||||
| Certifications | CE/FCC | ||||
| Dimensions | 260 mm × 170 mm × 28 mm (10.24″ × 6.69″ × 1.10″) | ||||
| Operating Temperature | -10°C to +55°C (+14°F to +131°F ) | ||||
| Operating Humidity | 10%RH–90%RH (No condensation) | ||||
| Power Consumption | ≤7W (Work) | ||||
