RUIJIE Wireless AP Indoor 802.11ac Access Point, Dual Band

3 years warranty c/w Lifetime Free Ruijie Cloud)

The Ruijie AP710 is a cost effective 802.11ac access point with 2×2 MIMO and concurrent Dual-band design, data rate of upto 1.167Gbps.
Taking advantage of Ruijie hybrid management flexibility, customer can choose the Ruijie Cloud Management and Hardware Controller for varies fast-changing business needs.
No matter cloud or hardware-based controller, all integrated with advanced radio optimization, wireless roaming as well as secure authentication out-of-box. The entry AP710 with balanced performance perfect for small to medium office, retail chains and budget hotel for their indoor scenarios.


Best Price-Performance Choice

With 802.11ac Concurrent Dual-Band design, the AP710 data rate is up to 1.167Gbps, sufficient for majority small office and retail store environment.

Plus 100% Cloud Management and 3-Year Warranty, the entry AP710 provides the perfect balanced of price performance for small-medium business users.


Migration from 11n to 11ac

The AP710 adopts 802.11ac standard with data rate up to 1.167Gbps, providing 2.5 times faster experience than previous generation of 802.11n


Hidden Cabling Design

The AP710 employs a simplistic and stylish design to fit different scenarios


Flexible Hybrid Management

3 different management modes for selection, perfect for your ever changing business needs


Zero Provisioning

No Software Installation

4-Step Fast Provisioning by Ruijie Cloud Mobile APP


RF Specifications
Radio Concurrent Dual-band
Protocol 802.11a/b/g/n/ac
Operating Bands – C5802.11b/g/n: 2.4GHz to 2.483GHz
– 802.11a/n/ac: 5.150GHz to 5.350GHz, 5.47GHz to 5.725GHz, 5.725GHz to C55.850GHz (vary depending on countries)
Antenna Built-in Antenna
Max Throughput 1167Mbps
Spatial Streams 2
Maximum Transmit Power 100mW
IP Rating IP41
Service Ports 1x 10/100/1000BASE-T Ethernet uplink
Console Ports 1x Console Port
Power Supply -local power supply (DC 5V/3A)
-PoE (802.3af)
Power Consumption <12.95W
Maximum clients per AP 256
BSSID capacity 32
Remote Intelligent Perception Technology (RIPT) Support
Intelligent load balancing based on the number of users or traffic Support
STA control Support
Bandwidth control Support
Preference for 5GHz (band select) Support
PSK, Web, 802.1x authentication Support
PPSK authentication Support
Data encryption WPA (TKIP), WPA2 (AES), WPA-PSK, and WEP (64 or 128 bits)
PEAP authentication Support
User isolation Support
Rogue AP detection and countermeasure Support
RADIUS Support
Wireless Intrusion Detection System(WIDS) Support
Wireless Intrusion Prevention System (WIPS) Support
IPv4 address Static IP address or DHCP reservation
IPv6 address Manual or automatic configuration
Multicast Multicast to unicast conversion
Management and Maintenance
Network management SNMP v1/v2C/v3, Telnet, TFTP, Web management
Cloud AC management Support
FAT/FIT switching Support
Physical Specification & Others
Lock Support
LED Indicators 1 LED indicator (red, green, blue, orange, and flashing modes, breathing flashing mode for smart device access, and the indicator can be switched off to enable silence mode)
Dimensions (W x D x H) (mm) 194 × 194 × 37
Weight 0.42kg
Environmental Specifications
Temperature Operating Temperature: -10°C to 50°C
Storage Temperature: -40°C to 70°C
Humidity Operating Humidity: 5% to 95% (non-condensing)
Storage Humidity: 5% to 95% (non-condensing)
Wi-Fi Alliance Certification Support
Radio Standard EN300 328
EN301 893
EMC Standard GB9254
EN301 489-1
EN301 489-17
Safety Standard GB4943
EN/IEC 60950-1
Not available.
Type Download
Hardware Installation Guide
Quick Installation Guide
RGOS Configuration Guide
RGOS Command Reference
Tolly Test Report
Title Remark Release notes Download
RG-AP710 AP_RGOS11.1(9)B1P19_S1C2-21_06200910_install Firmware (22.2M) 2019-08-13
RG-AP710 AP_RGOS11.1(5)B40P6_S1C2-21_06150511_install Firmware (21.4M) 2019-03-11
RG-AP710 AP_RGOS11.1(5)B40P2_S1C2-21_05151412_install Firmware (21.4M) 2018-08-14
