| Specifications | |||||
| Capacity | Fingerprints: 6,000 Cards: 10,000 |
||||
| Access Control Interface | Lock Relay Output Alarm Output/Auxiliary Input Exit Button/ Door Sensor Doorbell Output |
||||
| Communication | TCP/IP, RS485 (for slave reader) USB Host Wiegand Input/Output |
||||
| Hardware | SilkID Fingerprint Sensor 2.4 Inch TFT-LCD Touch Screen 125 kHz ZKAccess Card Reader Tamper Switch Alarm |
||||
| Standard Functions | Access Levels/Groups/Holidays DST/Bell Schedule Duress Mode (Password) Anti-Passback Record Query Custom Wallpaper & Screen Saver |
||||
| Software Compatibility | ZKBioSecurity | ||||
| Working Temperature | 14°F to 122°F (-10°C to 50°C) | ||||
| Dimensions | 7.7 x 3.5 x 1.4 inches (195.5 x 87 x 35mm) | ||||
| Package Includes | 12V 3A Power Supply | ||||
| Power | Operating Voltage: 12V DC | ||||
| Current Draw: <500mA | |||||
