IPC-HFW4431D-AS

4MP WDR LXIR Bullet Network Camera

Features:

  • 1/3” 4Megapixel progressive scan CMOS
  • H.265&H.264 triple-stream encoding
  • 25/30fps@4M(2688×1520)
  • Smart Detection supported
  • WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC
  • Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
  • 3.6mm fixed lens (6mm lens optional)
  • 1/1 Alarm in/out, 1/1 audio in/out
  • Max. IR LEDs Length 80m
  • Micro SD memory, IP67, PoE

Camera
Image Sensor 1/3” 4Megapixel progressive scan CMOS
Effective Pixels 2688(H)x1520(V)
RAM/ROM 512MB/32MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual, 1/3(4)~1/100000s
Minimum Illumination 0.08Lux/F2.0( Color,1/3s,30IRE)
0.3Lux/2.0( Color,1/30s,30IRE)
0Lux/F2.0(IR on)
S/N Ratio More than 50dB
IR Distance Distance up to 40m (131ft)
IR On/Off Control Auto/ Manual
IR LEDs 2
Lens
Lens Type Fixed
Mount Type Board-in
Focal Length 3.6mm (6mm optional)
Max Aperture F2.0 (F2.0)
Angle of View H: 87° (55°), V: 48° (31°)
Optical Zoom
Focus Control Fixed
Close Focus Distance
DORI Distance
DORI Distance
3.6 mm 6.0 mm
Detect 80m(262ft) 117m(384ft)
Observe 32m(105ft) 47m(154ft)
Recognize 16m(52ft) 23m(75ft)
Identify 8m(26ft) 12m(39ft)
Pan/Tilt/Rotation
Pan/ Tilt/ Range Pan:0˚~360˚; Tilt:0˚~87˚; Rotation:0˚~360˚
Intelligence
IVS Tripwire, Intrusion, Object Abandoned/Missing
Advanced Intelligent Functions Face Detection
Video
Compression H.265+/H.265/H.264+/H.264
Streaming Capability 3 Streams
Resolution 4M(2688×1520)/3M(2304×1296)/
1080P(1920×1080)/1.3M(1280×960)/
720P(1280×720)/D1(704×576/704×480)/
VGA(640×480)/CIF(352×288/352×240)
Frame Rate Main Stream: 4M(1~25/30fps)
Sub Stream: D1(1~25/30fps)
Third Stream: 720P(1~25/30fps)
Bit Rate Control CBR/VBR
Bit Rate H.264: 24~10240Kbps
H.265: 14~6144Kbps
Day/Night Auto(ICR) / Color / B/W
BLC Mode BLC / HLC / WDR(120dB)
White Balance Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control Auto/Manual
Noise Reduction 3D DNR
Motion Detection Off / On (4 Zone, Rectangle)
Region of Interest Off / On (4 Zone)
Electronic Image
Smart IR Support
Defog
Digital Zoom 16x
Flip 0°/90°/180°/270°
Mirror Off / On
Privacy Masking Off / On (4 Area, Rectangle)
Certifications
Certifications CE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B
Audio
Compression G.711a/ G.711Mu/ AAC/ G.726
Network
Ethernet RJ-45 (10/100Base-T)
Protocol HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP;FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP;IGMP; SNMP
Interoperability ONVIF, PSIA, CGI
Streaming Method Unicast / Multicast
Max. User Access 10 Users/20 Users
Edge Storage NAS
Local PC for instant recording
Micro SD Card 128GB
Web Viewer IE, Chrome, Firefox, Safari
Management Software Smart PSS, DSS, Easy4ip
Smart Phone IOS, Android
Interface
Video Interface
Audio Interface 1/1 channel In/Out
RS485
Alarm 1 channel In: 5mA 5VDC
1 channel Out: 300mA 12VDC
Electrical
Power Supply DC12V, PoE (802.3af)(Class 0)
Power Consumption <7.5W
Environmental
Operating Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Storage Conditions -30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress Protection IP67
Vandal Resistance
Construction
Casing Metal
Dimensions 241.8mm×90.4mm×90.3mm (9.52”×3.56”×3.56”)
Net Weight 0.61Kg (1.35lb)
Gross Weight 0.8kg (1.77lb)
