Dahua AI PTZ IP Cameras SD49225XA-HNR

2MP 25x Starlight IR WizSense Network PTZ Camera

Features:

  • 1/2.8” 2Megapixel CMOS
  • Powerful 25x optical zoom
  • Starlight technology
  • Max. 50/60fps@1080P
  • > Perimeter protection
  • Support PoE+
  • IR distance up to 100m
  • SMD PLUS
  • IP66



Dahua AI PTZ IP Cameras-SD49225XA-HNR

2MP 25x Starlight IR WizSense Network PTZ Camera

Camera

Image Sensor 1/2.8″ STARVIS™ CMOS
Effective Pixels 1920 (H) × 1080 (V), 2 Megapixels
Scanning System Progressive
ROM 4GB
RAM 1GB
Electronic Shutter Speed 1/1 s–1/30,000 s
Minimum Illumination Color: 0.005Lux@F1.6
B/W: 0.0005Lux@F1.6
0Lux@F1.6 (IR light on)
S/N Ratio N/A
Illumination Distance 100 m (328.08 ft)
Illumination On/Off Control Zoom Prio/Manual/SmartIR
Illumination Number 6

Lens

Focal Length 4.8 mm–120 mm
Max Aperture F1.6–F4.4
Angle of View H: 62.8°–2.6°; V: 33.2°–1.7°; D: 67.3°–3.9°
Optical Zoom 25x
Focus Control Auto/Semi-Auto/Manual
Close Focus Distance 0.1 m–1.5 m (0.33 ft–4.92 ft)
Iris Control Auto/Manual
DORI Distance
Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.
Distance
Detect 1613 m (5291.99 ft)
Observe 646 m (2119.42 ft)
Recognize 323 m (1059.71 ft)
Identify 161 m (528.22 ft)

Pan / Tilt / Rotation

Pan/Tilt/Rotation Pan: 0°–360° (endless)
Tilt: -15°–90° (auto flip 180°)
Manual Control Speed Pan: 0.1°–200°/s
Tilt: 0.1°–120°/s
Preset Speed Pan: 240°/s
Tilt: 200°/s
Presets 300
Pattern 5
Scan 5
Tour 8 (up to 32 presets per tour)
Speed Adjustment Support
Power-off Memory Support
Idle Motion Preset/Tour/Pattern/Scanning
Protocol DH-SD
Pelco-P/D (auto recognition)
General Intelligence
Event Trigger Motion detection, Video tampering, Network disconnection, IP address conflict, Illegal access, Storage anomaly
IVS Tripwire, Intrusion,Abandoned/Missing
Artificial Intelligence
People Counting N/A
Perimeter Protection Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc.
SMD Plus Support
Face Detection Support
Smart Capture Support human, motor vehicle and non-motor vehicle image capture.

Video

Compression H.265+/H.265/H.264+/H.264/MJPEG (sub stream)
Streaming Capability 3 Streams
Frame Rate Main stream: 1080P/1.3 M/720P (1–50/60fps)
Sub stream 1: D1/CIF (1–25/30fps)
Sub stream 2: 1080P/1.3M/720P/D1/CIF (1–25/30fps)
Resolution 1080P (1920 × 1080); 1.3 M (1280 × 960); 720P (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control Variable/Constant
Bit Rate H.264/H.265/MJPEG: 3 kbps–20480 kbps
Day/Night Auto(ICR) / Color / B/W
BLC Support
HLC Support
WDR 120dB
Gain Control Auto / manual
Noise Reduction Ultra DNR (2D/3D)
White Balance Auto, ATW, Indoor, Outdoor, Manual
Motion Detection Support
Region of Interest Support
Electronic Image Stabilization (EIS) Electronic
Defog Electronic
Digital Zoom 16x
Flip 180°
Privacy Masking Up to 24 areas, and up to 8 areas in the same view
Network
Ethernet RJ-45 (10XBase-T/100Base-TX)
Wi-Fi N/A
Protocol IPv4; IPv6; HTTP; HTTPS; SSL; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMPv1/v2c/v3(MIB-2); ARP; RTCP; RTSP; RTP; SMTP; NTP; DHCP; DNS; PPPOE; DDNS; FTP; IP Filter; QoS; Bonjour; 802.1x
Interoperability ONVIF Profile S&G&T; CGI
Streaming Method Unicast / Multicast
Max. User Access 19 users
Edge Storage NAS; Local PC; Micro SD card (256G)
Web Viewer IE7 and newer versions
Chrome 45 and newer versions
Firefox 52 and earlier versions
Safari (no version restrictions)
Management Software Smart PSS, DSS, DMSS
Smart Phone IOS, Android

Certifications

Certifications CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014
UL: UL62368-1+CAN/CSA C22.2,No. 62368-1
Audio
Compression G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G.722.1; G.729; G.723
Port
Video Interface N/A
RS485 N/A
Audio I/O 1
Alarm I/O 1
Alarm I/O 2/1

Power

Power Supply DC 12V/3A
PoE+ (802.3at)
Power Consumption 13W
22W (IR on)
Environmental
Operating Conditions -40°C to +70°C (-40°F to +158°F)
Operating Humidity ≤95%
Protection IP66; TVS 6000V lightning proof; surge protection
Structure
Casing N/A
Dimensions Φ160 mm × 295 mm (6.30″ × 11.61″)
Net Weight 3 kg (6.61 lb)
Gross Weight 4.8kg (10.58lb)
