| Specifications | |||||
| Number of Doors Controlled | 4 Door | ||||
| Number of Readers Supported | 4 | ||||
| Types of Readers Supported | 26-bit Wiegand, others upon request | ||||
| Number of Inputs | 12 (4 Exit Device, 4 Door Status, 4 AUX) | ||||
| Number of Outputs | 8 (4-Form C Relay for Lock and 4-Form C Relay for Aux Output) | ||||
| Card Holders Capacity | 30,000 | ||||
| Log Events Capacity | 100,000 | ||||
| Weight | 7.8lbs (3.55kg) | ||||
| Communication | TCP/IP and RS-485 | ||||
| Enclosure | Powder Coated Aluminium | ||||
| Mounting | Wall Mount | ||||
| Recommended Power Supply | 12V DC, 1.5A | ||||
| Dimensions (Bundle Only) | 15 in x 3.15 in x 11 in 380mm (L) x 80mm (W) x 280mm (H) |
||||
| Dimensions (Board Only) | 8.58 in x 4.17 in 218mm x 106mm |
||||
