| System | |||||
| Main Processor | 8 Bit | ||||
| Read | |||||
| Read Format | 125KHz | ||||
| Read Range | 3-6cm (max.) | ||||
| Reading time | <0.1s | ||||
| Function | |||||
| Water-proof | IP67 | ||||
| Interface | |||||
| To Controller | RS485,Wiegand 34(26 optional) | ||||
| General | |||||
| Beep Tone | Buzzer | ||||
| Ingress Protection | IP67, water resistant | ||||
| Power Supply | 9-15VDC/100mA | ||||
| Working Environment | -30°C~60°C | ||||
| Working Humidity | ≤95% | ||||
| Dimension (WxDxH) | 96mm*43mm*17mm | ||||
| Weight | 0.1Kg | ||||
